OEM ALL-IN-ONE HOME ENERGY STORAGE 5KWH Manufacturer, Supplier

Our Home Energy StorageÂ products are widely used by installers, agents, distributors, factories, and traders.

Elite Power 10kWhÂ battery features a lithium iron phosphate battery pack paired with a 5kW inverter. The battery pack is made up of 16 high-quality 100AH cells, configured in both series and parallel. With a well-engineered internal structure and cutting-edge battery production technology, it offers high energy density, long lifespan, exceptional safety, and reliable performance across a wide temperature range. This energy storage solution is a sustainable and eco-friendly option for your power needs.

Send Inquiry

Product Description

Product Description Product Details

Product Advantage

Grade A LiFePO4 Cells

Longer cycle life and enhanced safety.

01 Product details

Over 6000 Cycles

Maintains 80% DOD for long-lasting performance.

02 Product details

Built-in Air Cooling System

Effectively controls the internal temperature of the powerwall battery.

03 Product details

Exclusive Patented Interface Design

Unique and secure connection.

04 Product details

Multiple Communication Protocols

Supports RS232, RS485, and CAN for versatile integration.

05 Product details

Thermal Shock and Puncture Resistant

Withstands extreme conditions without fire or explosion.

06 Product details

Wide Inverter Compatibility

Works seamlessly with leading global inverter brands.

07 Product details

Real-time LCD Monitoring

Provides clear, live updates on battery status.

08 Product details

App Remote Control

Conveniently manage and monitor the system from anywhere.

09 Product details

Built-in Inverter

Simplifies installation and reduces equipment costs by integrating both battery and inverter in one compact unit.

10 Product details

Product Specification

Battery Cell	Specification Model	100Ah
	Capacity	100Ah
	Nominal Voltage	3.2V
	Internal Resistance	≤ 0.4mΩ
	Combination Mode	16S1P
	Grouping Standard	Tolerance < 1%
		Single Section Internal Resistance Range < 0.2mΩ
		Single Section Voltage Difference ≤ 5mV
		Charge Retention Capacity > 90%
Parameter	Nominal Voltage (V)	51.2
	Nominal Capacity (Ah)	100
	Charging Cut-off Voltage (V)	58.4
	Discharge Cut-off Voltage (V)	40
	Maximum Continuous Discharge Current (A)	100
	Standard Charging Current (A)	25
	Charging Temperature	0°C ~ 45°C
	Discharge Temperature	-20°C ~ 65°C
	Battery Size	1020 * 180 * 600mm
	Battery Weight	78Kg
	Storage Temperature Range	-20°C ~ 55°C
	Storage Humidity (% RH)	5% ~ 95% (No Condensation)
Management System	Single Overvoltage Protection Value	3.65V
	Overpressure Release Value	3.55V
	Single Undervoltage Protection Value	2.5V
	Undervoltage Release Value	2.7V
	Overcurrent Protection Value	110A
Inverter	Model	5048MH
Input	Input Source	L+N+PE
	Rated Input Voltage	220 / 230 / 240VAC
	Voltage Range	154-264VAC ± 3V (APL Mode) / 185-264VAC ± 3V (UPS Mode)
	Frequency	50Hz / 60Hz (Automatic Adaptation)
Output	Rated Capacity	5000W
	Output Voltage	220 / 230 / 240VAC ± 5%
	Output Frequency	50 / 60Hz ± 0.1%
	Wave Form	Pure Dazzle
	Transmission Time	Computer (UPS Mode) 10ms, Home device (APL Mode) 20ms
	Peak Power	10000VA
	Overload Capacity	Battery Mode: 21s @ 105% ~ 150% Load / 11s @ 150% ~ 200% Load / 400ms @ >200% Load
	Peak Efficiency (Battery Mode)	> 94%
Battery	Battery Voltage	48Vdc
	Constant Charge Voltage (Adjustable)	56.4Vdc
	Floating Charge Voltage (Adjustable)	54Vdc
Charger	PV Charging Mode	MPPT
	PV Input Maximum Power	5500W
	MPPT Tracking Range	120 ~ 500Vdc
	Optimum Voltage	300 ~ 400V
	PV Input Voltage Maximum	500Vdc
	PV Charging Current Maximum	80A
	AC Charging Current Maximum	80A
	Charging Current Maximum	80A
Display	Liquid Crystal Display	Display running mode / load / input / output, etc.
Environment	Operating Temperature	0 ~ 40°C
	Humidness	20% ~ 95% (Non-Condensing)
	Storage Temperature	-15 ~ 60°C
	Altitude	No more than 1,000 meters above sea level (derated above 1,000 meters, maximum 4,000 meters, refer to IEC62040)
	Noise	≤ 50 dB

Product Gallery

Frequently Asked Questions

What type of cells are used in this energy storage system?

This system utilizes Grade A LiFePO4 cells which provide a longer cycle life and enhanced safety compared to standard batteries.

How many charge/discharge cycles does the battery support?

The battery supports over 6000 cycles while maintaining an 80% Depth of Discharge (DOD) for long-lasting, reliable performance.

Is the system compatible with multiple inverter brands?

Yes, it features wide inverter compatibility and is engineered to work seamlessly with leading global inverter brands.

What communication protocols are available for integration?

The system supports multiple communication protocols including RS232, RS485, and CAN, ensuring versatile integration into various system setups.

How does the built-in inverter help with installation?

The built-in inverter integrates both the battery storage and power inverter into a single compact unit. This design simplifies installation, saves space, and reduces overall equipment costs.

How can I monitor the battery and system status?

You can monitor live status updates directly on the built-in Liquid Crystal Display (LCD) showing current modes, loads, input, and output. Additionally, you can manage and track the system remotely via a mobile App.
